TRUSTEC MOTOR YOUR TRUSTED FACTORY
Sales & Support:
 |
| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE、High-tech Enterprise Certificate、ISO9000 Certificate 2023 |
| Model Number: | YDK-80-6A |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100,000 pcs per month |
| High Light: | 900RPM Outdoor Fan Motor,Copper Leads Winding Fan Motor,80W Outdoor Fan AC Motor |
||
|---|---|---|---|
| Product Name | Outdoor Fan Motor | Voltage |
220V-240V |
|---|---|---|---|
| Frequency | 50 Hz | Output Power | 80W |
| Pole | 6P | AMPS | 0.82A |
| Speed | 900RPM | Capacitor | 4μF/450V |
| Insulation Class | Class B | Ingress Protection rating | IP44 |
| Other protection | THERMALLY PROTECTED | ||
Ralated Outline
Key Parameters
| Model Number |
Output Power /W |
Voltage /V |
Frequency /Hz |
Rated Speed /RPM |
Rated Current /A |
| YDK-80-6A | 80 | 220-240 | 50 | 900 | 0.82 |
Ps:all dimension can be customized according to customer requirement.
Product Features
1.Use NSK low noise high quality ball bearing;
2.Nickel plating for shaft, electrophoretic coating for enclosure;
3.Over-heating and over-current protection, rotation-clogging protection;
4.Multiple waterproof, anti-rust property, meet different working conditions;
5.Reasonable structure, high efficiency, low temperature rise, low noise, small vibration.
Product Application
1.Air refresher,indoor unit of air conditioner
2.Dehumidifier,disinfector
3.Air ventilation fan,air curtain
Our Advantages
1.ODM
2.One Stop Service
3.Solutions Supplier
4.Quality Guarantee
5.Focus and Commitment
6.Teamwork ability with quick response
FAQ
Q:Can I get a sample before the order because I really don't know how is your quality?
A:We can provide free sample service! Do not hesitate to send inquiry to get the free sample!
Q:What's the delivery time?Because we really need them is urgently?
A:7days For sending sample order. 20-30days for regular order , depends your order quantity.
Q:How to send a inquiry for more information?
A:When you send enquiry to us,please let us know your Wechat,Whapps or Skype Id,so that we can quote the offer at once. We are always on line waiting for you.
